Description
| Operating Conditions | |
| Max. Test Pressure | 24 |
| Pressure Class (Optional) | 16 |
| Max. Applicable Temperature | 200℃ |
| No | Part Name | Material |
| 1 | Body | GG25 / GG40.3 / WCB / SS304 / SS316 |
| 2 | Window Lock Piece | GG25 / AISI304 |
| 3 | Window Lock Bolt | Carbon Steel SAE Gr 5 / AISI304 |
| 4 | Lock Stud Nut | Carbon Steel SAE Gr 5 / AISI304 |
| 5 | Window Sealing Gasket | PTFE |
| 6 | Sight Window | Thermal Glass |
